MIL-DTL-3432J
TABLE IX. Jacket thickness.
Calculated core
Jacket thickness
diameter inches(mm),
Duty L
Duty M
Duty H
inclusive
Nominal
Minimum
Nominal
Minimum
Nominal
Minimum
in. (mm)
in. (mm)
in. (mm)
in. (mm)
in. (mm)
in. (mm)
.125 and under
.020
.018
.027
.024
.035
.032
(3.17 and under)
(.51)
(.46)
(.67)
(.61)
(.89)
(.81)
.126 to 0.155
.022
.019
.031
.028
.040
.036
(3.2 to 3.94)
(.56)
(.48)
(.79)
(.71)
(1.02)
(.91)
.156 to .219
.024
.022
.039
.035
.045
.041
(3.96 to 5.56)
(.61)
(.56)
(.99)
(.89)
(1.14)
(1.04)
.220 to .234
.026
.023
.039
.035
.078
.070
(5.59 to 5.94)
(.66)
(.58)
(.99)
(.89)
(1.98)
(1.78)
.235 to .290
.031
.028
.047
.042
.078
.070
(5.97 to 7.37)
(.79)
(.71)
(1.19)
(1.07)
(1.98)
(1.78)
.291 to .300
.031
.028
.047
.042
.094
.085
(7.39 to 7.62)
(.79)
(.71)
(1.19)
(1.07)
(2.39)
(2.16)
.301 to .430
.050
.045
.063
.057
.094
.085
(7.65 to 10.9)
(1.27)
(1.14)
(1.6)
(1.45)
(2.39)
(2.16)
.431 to .540
.070
.063
.094
.085
(10.9 to 13.7)
(1.78)
(1.6)
(2.39)
(2.16)
.541 to .640
.078
.070
.109
.098
(13.7 to 16.3)
(1.98)
(1.78)
(2.77)
(2.49)
.641 to .740
.094
.085
.125
.113
(16.3 to 18.8)
(2.39)
(2.16)
(3.17)
(2.87)
.741 to .850
.109
.098
.141
.127
(18.8 to 21.6)
(2.77)
(2.49)
(3.58)
(3.23)
.851 to 1.100
.125
.113
.156
.140
(21.6 to 27.9)
(3.17)
(2.87)
(3.96)
(3.56)
1.101 to 1.320
.156
.140
.172
.155
(28 to 33.5)
(3.96)
(3.56)
(4.37)
(3.94)
1.321 to 1.550
.172
.155
.188
.169
(33.6 to 39.4)
(4.37)
(3.94)
(4.78)
(4.29)
1.551 to 1.820
.203
.183
(39.4 to 46.2)
(5.16)
(4.65)
1.821 to 2.050
.220
.198
(46.3 to 52.1)
(5.59)
(5.03)
2.051 to 2.300
.235
.212
(52.1 to 58.4)
(5.97)
(5.38)
2.301 to 2.550
.250
.225
(58.4 to 64.8)
(6.35)
(5.71)
2.551 to 2.800
.265
.239
(64.8 to 71.1)
(6.73)
(6.07)
2.801 to 3.100
.280
.252
(71.1 to 78.1)
(7.11)
(6.4)
3.101 to 3.500
.295
.266
(78.8 to 88.9)
(7.49)
(6.76)
3.501 to 3.950
.310
.279
(88.9 to 100)
(7.87)
(7.09)
3.951 to 4.450
.330
.297
(100 to 113)
(8.38)
(7.54)
4.451 to 5.00
.345
.311
(113 to 127)
(8.76)
(7.9)
3.2.7.1 Polyurethane jacket. For medium and heavy-duty cables, the jacket shall be reinforced with polyester or
glass fiber strands treated (if necessary) to bond to polyurethane. The fibers shall be applied over the cable core and
bonded to the jacket.
