INCH-POUND
MIL-DTL-3432J
22 December 2009
SUPERSEDING
MIL-DTL-3432H
23 January 2006
DETAIL SPECIFICATION
CABLES, (POWER AND SPECIAL PURPOSE) AND WIRE, ELECTRICAL
(300 AND 600 VOLTS)
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers single and multiple conductor cables with and without shields for use in 300
and 600 volts root mean square (rms) applications (see 6.1).
1.2 Classification. Cables covered in this specification are furnished in accordance with the type designation
specified and are classified by the element thereof.
1.2.1 Type designation. The type designation is formed as follows:
08
HG
E
(2/16S-4/12)
SJ
1090
M 3432 -
Part or
Total number
Class
Flexibility
Conductor
Shielding under
Outside
Identifying
of conductors
(1.2.1.3)
(1.2.1.4)
data
jacket
diameter
(1.2.1.6)
(1.2.1.7)
Number (PIN)
(1.2.1.2)
(1.2.1.5)
(1.2.1.1)
1.2.1.1 PIN. Cables covered by this specification are identified by "M3432" followed by a hyphen.
1.2.1.2 Total number of conductors. The total number of conductors (see 6.3.1) in a cable, exclusive of ground
wires (see 6.3.2 and 6.3.4), is identified by a two-digit number. For cables with less than 10 conductors, a "0"
precedes the number of conductors (example - 04 means 4 conductors) in a multiple conductor power cable.
