MIL-DTL-28830E
TABLE IV. Qualification inspection.
Inspection
Requirement
Test method
paragraph
paragraph
Leak test (type I only)
Attenuation
VSWR
Impedance
Velocity of propagation (when specified, see 3.1)
Capacitance (when specified, see 3.1)
Cold bend (jacketed cable only)
Flexibility
Temperature cycling
Thermal shock
Flame propagation (type IV jacketed cable only)
Acid gas generation (type IV jacketed cable only)
Halogen content (type IV jacketed cable only)
Smoke index (type IV jacketed cable only)
Toxicity index (type IV jacketed cable only)
Tensile strength and elongation (unaged) (types II and IV only)
4.5.3 Retention of qualification. To retain qualification, the contractor shall forward a report at 12
month intervals to the qualifying activity. The qualifying activity shall establish the reporting date.
The report shall consist of the following:
a. A summary of the results of the test performed for inspection of product for delivery,
groups A and B, indicating, as a minimum, the number of lots that have passed and
the number that have failed. The results of tests of all reworked lots shall be
identified and accounted for.
b. The results of tests performed for periodic inspection, group C, including the number
and mode of failures. The report shall include results of all periodic inspection tests
performed and completed during the 12-month period. If the test results indicate
nonconformance with specification requirements, and corrective action acceptable to
the qualifying activity has not been taken, action may be taken to remove the failing
product from the qualified products list.
Failure to submit the report within 60 days after the end of the 12-month period may result in loss of
qualification for the product. In addition to the periodic submission of inspection data, the contractor
shall immediately notify the qualifying activity at any time during the 12-month period that the
inspection data indicates failure of the qualified product to meet the requirements of this specification.
In the event that no production occurred during the reporting period, a report shall be submitted
certifying that the company still has capabilities and facilities necessary to produce the item. If during
two consecutive reporting periods there has been no production, the manufacturer may be required,
at the discretion of the qualifying activity, to submit group C test results covering a representative
product from each group as defined by 4.6.
4.6 Conformance inspections.
4.6.1 Inspection of product for delivery. Inspection of product for delivery shall consist of groups A
and B inspections.
8
