MIL-DTL-13777/5D
TABLE II. Design data Continued.
DESIGN DATA
Type designation
371065S
371142
Figure number
4
5
Total wires
37
37
Number of conductors & AWG #
4/#18S
27/#18
6/#14
37/#18
Insulation
Minimum average thickness
0.015"
0.015"
Spark test voltage
3000
3000
Inspection test voltage
1500
1500
Cabling
Layer 1
Filler
(a) Number of wires
4
5/
(b) AWG #
#18S
(c) Maximum lay
3.00"
Layer 2
(a) Number of wires
6
6
7
(b) AWG #
#18
#14
#18
(c) Maximum lay
5.00"
Layer 3
(a) Number of wires
21
12
(b) AWG #
#18
#18
(c) Maximum lay
6.00"
Layer 4
(a) Number of wires
18
(b) AWG #
#18
(c) Maximum lay
7.00"
Sheath
Number of layers
1
2
Total thickness minimum
0.080"
0.140"
Minimum OD cable
1.050"
1.112"
Maximum OD cable
1.080"
1.172"
Maximum weight (lbs./1000ft.)
703
