MIL-DTL-24643C
TABLE V. Cable lengths.
Remnant lengths
Standard lengths
Random
Scrap
Nominal
price reduction
Type of
no price
lengths no price
lengths not
length
reduction
reduction
acceptable
package
5 percent
10 percent
(feet)
(feet)
(feet)
(feet)
(feet)
(feet)
Coil
500
550 to 450
449 to 150
149 to 100
99 to 50
49 to 0
Coil
600
660 to 540
539 to 180
179 to 120
119 to 60
59 to 0
Reel
500
550 to 450
449 to 150
149 to 100
99 to 50
49 to 0
Reel
800
880 to 720
719 to 240
239 to 160
159 to 80
79 to 0
Reel
1000
1100 to 900
899 to 300
299 to 200
199 to 100
99 to 0
Reel
1500
1650 to 1350
1349 to 450
449 to 300
299 to 150
149 to 0
Reel
2000
2200 to 1800
1799 to 600
599 to 400
399 to 200
199 to 0
Reel
2500
2750 to 2250
2249 to 750
749 to 500
499 to 250
249 to 0
Reel
3000
3300 to 2700
2699 to 900
899 to 600
599 to 300
299 to 0
3.9.2.1 Year marking. In addition to any other required marking, coils shall be marked with a keyed series of
colors to indicate the year of manufacture. This marking shall consist of a stripe approximately 2 inches wide and
colored for the particular year of manufacture. The cycle of colors shall be the same as those used for year marking
on reels (see 3.9.1.2).
3.9.2.2 Identification. Two shipping tags shall be securely attached to each coil, one inside and one outside the
wrapping, and marked with the following information.
a.
Type and size of cable.
b.
Footage.
c.
Contract or order number.
d.
Contractor's name.
e.
Manufacturer's name (if other than contractor).
f.
Gross weight.
4. VERIFICATION
4.1 Classification of inspections. The inspection requirements specified herein are classified as follows:
a.
Qualification inspection (see 4.3).
b.
Conformance inspection (see 4.4).
4.2 Inspection conditions. Unless otherwise specified, all inspections shall be performed in accordance with
the test conditions specified in 4.5.
4.3 Qualification inspection. Qualification inspection shall consist of the inspections specified in tables VI and
VIII and in accordance with the applicable specification sheet.
20
