INCH-POUND
MIL-DTL-24643C
1 October 2009
SUPERSEDING
MIL-DTL-24643B
22 August 2002
DETAIL SPECIFICATION
CABLES, ELECTRIC, LOW SMOKE HALOGEN-FREE, FOR SHIPBOARD USE
GENERAL SPECIFICATION FOR
This specification is approved for use by all Departments and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers low smoke halogen-free electric cable for Navy shipboard applications.
1.2 Classification. Cables covered by this specification are classified as watertight, watertight (with circuit
integrity), and non-watertight constructions, armored, and unarmored, unarmored with overall shield and further
classified for flexing and nonflexing service for power, lighting, control, communications, instrumentation and
electronic applications (see supplement). A part number for cable is as specified in 1.3 and the applicable
specification sheet.
1.3 Part number or identifying number (PIN). PINs to be used for low smoke halogen-free electric cable
acquired to this specification are created as follows:
M
24643
/XX
-
XX
A or U
O or D or N
Dash Number
Specification
Specification
A = Armored
O = Overall shield
Prefix
(See
Number
Sheet Number
U = Unarmored
D = Double overall
Specification
shielded
Sheets)
N = Not shielded
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements of documents cited in sections 3, 4, or 5 of this
specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract.
FEDERAL STANDARDS
FED-STD-228
-
Cable and Wire, Insulated; Methods of Testing
Comments, suggestions, or questions on this document should be addressed to: Commander, Naval Sea Systems
Command, ATTN: SEA 05B5, 1333 Isaac Hull Avenue, SE, Stop 5160, Washington Navy Yard DC 20376-5160 or
emailed to CommandStandards@navy.mil, with the subject line "Document Comment". Since contact information
can change, you may want to verify the currency of this address information using the ASSIST Online database at
https://assist.daps.dla.mil.
AMSC N/A
FSC 6145
