INCH-POUND
MIL-DTL-13777/2C
14 June 2011
SUPERSEDING
MIL-C-13777/2B
15 September 1969
DETAIL SPECIFICATION SHEET
CABLE, SPECIAL PURPOSE, ELECTRICAL
6, 7, 8, 9, 10, 12, 13, AND 15 CONDUCTORS
Inactive for new design after 1 July 2002.
This specification is mandatory for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-13777.
REQUIREMENTS:
Dimensions and configurations: See applicable figure and design data for the following cable types
specified in table I. Design data is shown in table II.
TABLE I. Cable types.
060410S
070618
080766
100660
150885
060480
070730
080840
100870
150915S
060565
070823S
080918
101091
061530
070930
090540
120620
061805
071090
090675
120650S
070590
S080625
100595
130685
In any conflict between the design data and the applicable figure, the design data shall govern.
AMSC N/A
FSC 6145
