MIL-DTL-55036C
4.9 Repairs.
4.9.1 Stranded conductor splices. Conductor strand splices shall conform to the requirements of 3.4.1.
4.9.1.1 Copper strands. Copper strand splices shall conform to the requirements of 3.4.1.1.
4.9.1.2 Steel strands. Test the steel strand joint to determine that the tensile strength of the strand
containing the joint is equal to not less than 35 percent of the average tensile strength of the strand
adjacent to the joint (see 3.4.1.2).
4.9.2 Insulation repairs. Test specimens of repaired insulation to determine compliance with the
requirements of 3.4.2.
4.9.3 Jacket repairs. Jacket repairs shall be in accordance with the contracting officer's written
approval (see 3.4.3).
4.9.4 Visual and mechanical inspection. Equipment shall be examined for the defects listed in table VII
and meet the requirements of 3.5.
TABLE VII. Visual and mechanical defects.
Defect
Incorrect number of strands.
Copper strands not correct size.
Steel strands not correct size.
Color code not correct or clear.
Pairing not correct.
Cabling not correct.
Inner jacket not correct thickness.
Braid not correct size or adequate.
Outer jacket not correct thickness.
Cable diameter not correct.
Conductor not centered within insulation.
Core wrap inadequate or not correctly wound.
Inner jacket not centered.
Braid contains loose strands.
Outer jacket not centered.
Identification marking not correct.
15
