MIL-DTL-49055F

3.20 Durability of identification. The identification marking shall withstand a minimum of 125 cycles

(250 strokes) when tested as specified in 4.6.17.

3.21 Shrinkage. The cable shall have no separation of the insulation and the insulation shrinkage shall

be not greater than that specified in the applicable specification sheet (see 3.1) when tested as specified

in 4.6.18.

3.22 Workmanship. The cable shall be free of kinks, abrasions, and cracked or peeled surfaces. The

cable shall be a uniform and consistent product and shall be free from defects that adversely affect the

serviceability of the product.

4. VERIFICATION

4.1 Classification of inspections. The inspection requirements specified herein are classified as

follows:

a. Qualification inspection (see 4.4).

b. Conformance inspection (see 4.5).

4.2 Requirements cross-reference matrix. Table III provides a cross-reference matrix of section 3

requirements tested or verified in the document.

TABLE III. Requirements cross-reference matrix.

Requirement

Verification paragraph

Verification paragraph Requirement paragraph

paragraph

4.3 Inspection conditions. Unless otherwise specified (see 6.2), all inspections shall be conducted

under the following ambient conditions: 77�18�F, site pressure, and site uncontrolled relative humidity.

The establishment and maintenance of a calibration system to control the accuracy of the measuring and

test equipment shall be in accordance with NCSL-Z540.3.
