MIL-DTL-3702F
CABLE SAMPLE
6.0 (152.0)
TEST AREA
BLUE FLAME
2.0
(50.8)
INNER CONE
0.75
(19.0)
FLAME SPREADER
BUNSEN
BURNER
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
FIGURE 5. Test setup for flammability test.
