INCH-POUND
MIL-DTL-3702F
18 April 2012
SUPERSEDING
MIL-DTL-3702E
15 January 2009
DETAIL SPECIFICATION
CABLE, POWER, ELECTRICAL: IGNITION,
HIGH-TENSION
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers shielded and unshielded electrical power cable for use on high-
tension ignition systems (see 6.1).
1.2 Classification. Cable is classified as to type of shielding, cable diameter, temperature limit,
conductor material, and cable application.
1.2.1 Type designation. The type designation should include specification number-based cable
M 3702
U
5
L
S
A
Cable application (see 1.2.1.6).
Conductor material (see 1.2.1.5).
Temperature limit (see 1.2.1.4).
Cable diameter (see 1.2.1.3).
Type of shielding (see 1.2.1.2 ).
Specification number (see 1.2.1.1).
Prefix M (see 1.2.1.1).
1.2.1.1 Specification number. The type designation will consist of the defense specification number
with the prefix M.
1.2.1.2 Type of shielding. The type of shielding is identified by the letter U or S as follows:
U - Unshielded
S Shielded
Comments, suggestions, or questions on this document should be addressed to DLA Land and
Maritime, ATTN: VAI, P.O. Box 3990, Columbus, OH 43218-3990, or email to WireCable@dla.mil.
Since contact information can change, you may want to verify the currency of this address
information using the ASSIST Online database at https://assist.daps.dla.mil.
AMSC N/A
FSC 6145
