MIL-DTL-3702F
CLAMP FOR HOLDING CABL E
PORTION OF CABLE UNDER TEST
TENSILE LOAD
APPL IED H ERE
6.0 (1 52.0)
MINI MUM
STATIONARY
M OVABLE FIXTU RE
FIXTURE
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
FIGURE 1. Test setup for tensile load test.
