MIL-DTL-3702F
TABLE VI. Qualification test sequence.
Specimen number (see 4.4)
Test sequence number
Test description
1/ 2/
4.7.1
Materials and construction
1/
4.7.3.3
Insulation flows
1/
4.7.2
Defects
1
Copper strands (coating)
2
Tensile load
3
Capacitance
3/
4
Life cycle
Maximum voltage
5
Low temperature
Maximum voltage
6
High temperature and altitude
Maximum voltage
7
Hot oil
Maximum voltage
8
Flammability
9
Anti-icing fluid
Maximum voltage
10
Fungus
Maximum voltage
11
Corona effect
Maximum voltage
3/
12
Liquid immersion for Air Force
aircraft applications
1/ Applies to the length of cable used for testing, or another representative length in accordance with
4.4.
2/ See copper strands for tests specified in 4.7.1.
4.4.1 Air Force aircraft qualification sample. Air Force aircraft qualification samples (see 1.2.1.6)
shall require an additional 120 feet of cable for the liquid immersion tests specified in 4.7.3.5.4.
4.4.2 Failure. Failure of a qualification sample to pass any of the inspections specified herein may
be cause for rejection.
13
