MIL-DTL-27072 Cable, Power, Electrical And Cable, Special Purpose, Electrical, Multiconductor And Single Shielded, General Specification ForThis specification covers special purpose electrical multi-conductor and single shielded cable for electronic circuits where the cable will be protected in racks, tunnels, or within buildings, trailers, or equipment. Cables constructed using polyvinyl chloride \(PVC\) on insulated wires or for fillers, tapes, or jackets are not to be used for aerospace applications.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12


. .
MIL-DTL-27072E
APPENDIX A
TABLE A-II.
Cross-reference of former component jacket material class and
designator to current component jacket material designator.
Jacket material
Former class
MIL-C-27072B
MIL-DTL-27072C
designator
designator
Polyamide
A
E, F, G, H
E, G, H (F deleted)
PVC
B
Z, J, K, L
Z, K, L (J deleted)
Polyethylene
C
M, N, O, P
Deleted
FEP
D
R, S, T, U
Deleted
Glass braid yarn
E
V, W, X, Y
Deleted
A.3.1 Shield and jacket undershield material cross-reference. Copper braid round shield material
was specified in MIL-C-27072B but is not specified in MIL-DTL-27072C. Shield and jacket undershield
designations B, F, and J (unjacketed) associated with copper braid round shield material used in
MIL-C-27072B were deleted from MIL-DTL-27072C.
A.4 Sheath material cross-reference. Cross-reference of former style and sheath material
designators to current sheath material designator (see 1.2.1.1) is shown in table A-III.
TABLE A-III. Cross-reference of former style and sheath material
designators to current sheath material designators.
Sheath material
Former
MIL-C-27072B
MIL-DTL-27072C
style
designator
designator
PVC
1
A
A
Polyethylene
2
B
B
Polychloroprene
3
C
Deleted
FEP
4
D
D
PTFE
5
E
E
Polyamide
6
F
Deleted
Glass braid yarn
7
G
Deleted
Polyurethane
8
H
Deleted
No sheath
-
K
Deleted
24
