MIL-DTL-27072E
1.2.1.2 Shield and jacket undershield material designator. Cable shield and jacket undershield
material designator using a single letter in accordance with table I.
TABLE I. Shield and jacket undershield material designator.
Jacket undershield material
Shield material
1/
PVC
Unjacketed
Polyamide
No shield
A
E
Z
Tinned copper round
C
G
K
Silver-coated copper round
D
H
L
1/ PVC is not to be used in aerospace applications.
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this
specification. This section does not include documents cited in other sections of this specification or
recommended for additional information or as examples. While every effort has been made to ensure the
completeness of this list, document users are cautioned that they must meet all specified requirements of
documents cited in sections 3, 4, or 5 of this specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and
handbooks form a part of this document to the extent specified herein. Unless otherwise specified,
the issues of these documents are those cited in the solicitation or contract.
FEDERAL STANDARD
FED-STD-228
-
Cable and Wire, Insulated; Methods of Testing
DEPARTMENT OF DEFENSE SPECIFICATIONS
MIL-I-631
-
Insulation, Electrical, Synthetic-Resin Composition, Non-rigid
MIL-DTL-16878/1
-
Wire, Electrical, Type B, 105ºC, 600 Volts (Insulated, High
Temperature)
MIL-DTL-16878/17
-
Wire, Electrical, Polyvinyl Chloride (PVC) Insulated, 105ºC, 600
Volts, Polyamide Jacket
MIL-DTL-16878/18
-
Wire, Electrical, Polyvinyl Chloride (PVC) Insulated, 105ºC, 1000
Volts, Polyamide Jacket
(See supplement 1 for list of specification sheets.)
2
