MIL-DTL-13777/4C
TABLE II. Design data Continued.
Design data
Type designation
321355
Figure number
10
Total wires
48
7/
Number of conductors & AWG #
Insulation
Minimum average thickness
0.015"
Spark test voltage
3000
Inspection test voltage
1500
Cabling
Layer 1
Filler
Layer 2
(a) Number of wires
5
(b) AWG #
#16
#20
(c) Maximum lay
2.0"
Layer 3
(a) Number of wires
11
(b) AWG #
#16
#20
(c) Maximum lay
6.5"
Sheath
Number of layers
2
Total thickness minimum
0.100"
Minimum OD cable
1.325"
Maximum OD cable
1.385"
Maximum weight (lbs./1000ft.)
945
1/ Shielded pairs
2/ Shielded triplets
3/ 2 Shielded pairs
4/ 4 Shielded pairs
5/ 4 Shielded triplets
6/ Shielded pairs AWG#18 with 3" Max lay twist
7/ 32 #16 shielded pairs w/16 #20 bare
7
