MIL-DTL-915/22J
TABLE I. Details.
Overall diameter (inches)
Size
Type TSP
Number of
pairs
Min
Max
11
11
0.680
0.730
31
31
0.982
1.062
EXAMINATION AND TESTS:
Requirements
Basic electrical:
Conductor resistance ohms/1000 feet at 25°C, maximum.............................................18.73
Voltage withstand - volts, root mean square, minimum
Conductor to conductor..........................................................................................2000
Conductor to water ................................................................................................. 1000
Insulation resistance megohms-1000 feet, minimum
Conductor to conductor and conductor to water ..................................................... 100
Group A:
Visual and dimensional.............................................................................................. No failure
Watertightness - see MIL-DTL-915, Table XXIII, for limits of water leakage....... No failure
Group B:
Physicals (unaged)
Insulation (conductor)
Tensile strength - lbf/in2, minimum...........................................................1800
Elongation - percent, minimum...................................................................125
Jacket (cable)
Tensile strength - lbf/in2, minimum...........................................................2300
Elongation - percent, minimum...................................................................250
Drip - at 95 ± 1°C....................................................................................... Zero
Group C:
Flammability - inches, maximum ......................................................................................................... 2
Physicals (aged)
Insulation (conductor)
Air oven
Elongation - percent of unaged, minimum....................................................80
Jacket (cable)
Air oven (168 hours at 136°C)
Tensile strength - percent of unaged, minimum............................................80
Elongation - percent of unaged, minimum....................................................60
Hot oil immersion
Tensile strength - percent of unaged, minimum............................................75
Elongation - percent of unaged, minimum....................................................50
Permanence of printing, , (jacket) - cycles, minimum ..................................................................... 250
2
