MIL-DTL-49104C
3.5.4 Attenuation. The attenuation of each pair of conductors shall not exceed the range of values
shown on figure 2 under both wet and dry conditions. The dry readings shall be not more than 30%
below the wet readings.
3.5.5 Crosstalk. The crosstalk to an adjacent similar cable shall be at least 55 dB down.
3.6 Flatness. The cable shall lie flat and straight when uncoiled from a reel or a spool or dispenser
onto a level surface.
3.7 Workmanship. The conductors, insulation and cable shall be uniform in quality and free from
defects that affect performance, serviceability, or appearance, such as lumps, kinks, splits, abrasions,
scrapes, corroded surfaces, skin impurities, and faulty extruded surfaces.
6
5
4
3
2.8
2
1.44
1
0
0.3
0.5
1.0
2.0
4.0
Frequency in kHz
FIGURE 2. Attenuation.
5
