MIL-DTL-27500H
Table I B Jacket material and color
continued;
Single
double
Temperature limit
jacket
jacket
Jacket material
for jacket material
symbol
symbol
(information only)
20
70
Extruded white perfluoroalkoxy (PFA)
260°C (500°F)
21
71
Extruded clear perfluoroalkoxy (PFA)
260°C (500°F)
22
72
Tape of polyimide combined with clear fluorinated ethylene propylene (FEP)
200°C (392°F)
wrapped and heat sealed with opaque polyimide outer surface
23
73
White, crosslinked, extruded, modified, ethylene-tetrafluoroethylene
200°C (392°F)
copolymer (XLETFE)
24
74
Tape layer of white polytetrafluoroethylene (PTFE) wrapped over a tape layer
200°C (392°F)
of natural polyimide combined with FEP and heat sealed.
2. APPLICABLE DOCUMENTS.
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification. This section does not
include documents cited in other sections of this specification or recommended for additional information or examples. While every
effort has been made to ensure the completeness of this list, document users are cautioned that they must meet all specified
requirements of the documents cited in sections 3 and 4 of this specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards and handbooks. The following specifications, standards, and handbooks form a part of this
specification to the extent specified herein. Unless otherwise specified, the issues of these documents will be those listed in the issue
of the Department of Defense Index of Specifications and Standards (DoDISS) and supplement thereto, cited in the solicitation (see
6.2).
SPECIFICATIONS
Department of Defense
MIL-W-5086
-
Wire, Electrical, Polyvinyl Chloride Insulated, Copper or Copper Alloy.
MIL-W-8777
-
Wire, Electrical, Silicone-Insulated, Copper, 600 Volt, 200° C.
MIL-C-12000
-
Cable, Cord, and Wire, Electric; Packaging of.
MIL-W-22759
-
Wire, Electric, Fluoropolymer-insulated, Copper Or Copper Alloy.
MIL-W-25038
-
Wire, Electrical, High Temperature And Fire Resistant, General specification For
MIL-W-81044
-
Wire, Electric, Crosslinked Polyalkene, Crosslinked Alkaneimide Polymer, or
Polyarylene Insulated Copper Or Copper Alloy.
MIL-W-81381
- Wire, Electric, Polyimide-insulated, Copper or Copper Alloy.
5
