MIL-DTL-27500H
Table I B
Jacket materials and color
Single
Double
Temperature limit
jacket
jacket
Jacket material
limit for jacket
symbol
symbol
material
(information only)
00
00
No Jacket
---
90° C (194°F)
511/
01
Extruded white polyvinyl chloride (PVC)
522/
02
Extruded clear polyamide in accordance with ASTM D4066
105°C (221°F)
03
White polyamide braid impregnated with clear polyamide finisher over a
53
105°C (221°F)
polyester tape
04
54
Polyester braid impregnated with high temperature finishers over polyester
150°C (302°F)
tape
05
55
200°C (392°F)
Extruded Clear fluorinated ethylene propylene (FEP)
06
56
260°C (500°F)
Extruded or taped and heat sealed white polytetrafluoroethylene (PTFE)
07
57
260°C (500°F)
White polytetrafluoroethylene (PTFE) treated glass braid impregnated and
coated with polytetrafluoroethylene finisher over presintered
polytetrafluoroethylene tape
083/
583/
150°C (302°F)
Cross linked white extruded polyvinylidene fluoride (PVF2)
09
59
200°C (392°F)
Extruded white fluorinated ethylene propylene (FEP)
3
3
10 /
60 /
125°C (257°F)
Extruded clear polyvinylidene fluoride (PVF2)
4/
4/
11
61
200°C (392°F)
Tape of natural polyimide combined with clear fluorinated ethylene propylene
(FEP) wrapped and heat sealed with (FEP) outer surface
124/
624/
200°C (392°F)
Tape of natural polyimide combined with fluorinated ethylene propylene
(FEP) wrapped and heat sealed with polyimide outer surface
14
64
150°C (302°F)
Extruded white ethylene-tetrafluoroethylene copolymer (ETFE)
15
65
150°C (302°F)
Extruded clear ethylene-tetrafluoroethylene copolymer (ETFE)
16
66
200°C (392°F)
Braid of aromatic polyamide with high temperature finisher over presintered
polytetrafluoroethylene (PTFE) tape
175/
675/
150°C (302°F)
White extruded ethylene chlorotrifluoro-ethylene (ECTFE)
5/
5/
18
68
150°C (302°F)
Clear extruded ethylene chlorotrifluoro-ethylene (ECTFE)
1/ Polyvinyl chloride materials shall not be used for aerospace applications.
2/ Jacket material 02 is not to be used for cables having a diameter of 0.251 inch (6.88) or greater
3/ Jacket materials 08, 58, 10 and 60 are not to be used for cables having a diameter of 0.401 inch(10.19mm)or
greater.
4/ Not for Naval Air Systems Command Usage
5/ Inactive for new design
