MIL-DTL-27500H
TABLE VI.
Thermal shock and aging stability.
Jacket Materials
Thermal shock and aging
stability temperature
01
136°C
02, 03, 04, 10
150°C
14, 15,17, 18
180°C
05, 09, 11, 12, 16, 22, 24
230°C
06, 07, 20, 21
285°C
4. VERIFICATION.
4.1 Classification of inspection. The inspection requirements specified herein are classified as follows:
a. Quality conformance inspection (see 4.2.1).
b. Process control tests (see 4.2.2).
4.2 Inspection conditions. Unless otherwise specified , all inspections shall be performed in accordance with the test conditions
specified in MIL-STD-2223. .
4.2.1 Quality conformance inspection .
Quality conformance tests shall consist of the tests listed in table VII.
TABLE VII. Quality conformance inspection.
Test
Requirement
Test Method
Cable Lay-up
1/
3.5
4.2
Shield Coverage
1/
3.7.3
4.3.5
Braid angle
1/
3.7.2
4.3.5
Identification of product
3.9
4.3.1
Jacket wall thickness and
3.7.5 & 3.7.6
4.3.13 & 4.3.16
Concentricity
1/
3.7.5
4.3.17
Cable jacket removability 1/
3.11
4.4
Cable diameter
3.12
4.5
Cable weight
3.8.9
4.3.14
Lamination sealing
1/
3.8.4
4.3.6
Cold bend
1/
3.8.5
4.3.9
Thermal Shock
1/
3.8.6
4.3.10
Aging stability
1/
Jacket, tensile strength
1/
3.7.5.1
4.3.13.1
elongation
3.8.7
4.3.15
Blocking
1/
3.8.8
4.6
Flammability
1/
3.8.10
4.3.11
Crosslinked verification1/
3.8.11
4.3.18
Shield solderability
1/
1/When required
