MIL-DTL-27072/66D
TABLE I. Construction data.
Basic wire except color
SAE-AS22579/9-22* 1/
Finished cable
or NEMA HP3-EEWFEB*
diameter
(reference)
PIN M27072/66
inch (mm)
±10% 2/
Wire
Nominal
Number of
Strand size
size
diameter
strands
Inch (mm)2/
(AWG)
LEDD*
22
19
34
.060 (1.52)
.250 (6.35)
1/ SAE AS22759/9-22* color code is in accordance with MIL-STD-681.
Asterisks (*) shall be replaced by the appropriate color designator.
2/ Dimensions are in inches. Metric equivalents are given for information only.
Marginal notations are not used in this revision to identify changes with respect to the previous issues due
to the extensiveness of the changes.
In addition to MIL-DTL-27072, this document referenced the following:
MIL-STD-681
CONCLUDING MATERIAL
