INCH-POUND
MIL-DTL-27072/66D
6 August 2006
SUPERSEDING
MIL-DTL-27072/66C
8 December 2000
DETAIL SPECIFICATION SHEET
CABLE, SPECIAL PURPOSE, ELECTRICAL, MULTICONDUCTOR
(7 CONDUCTORS) AND SINGLE SHIELDED,
M27072/66LEDD*
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-27072C.
SHEATH FLUORINATED
ETHYLENE PROPYLENE
SHIELD SILVER
BLUE
COATED COPPER
BROWN
YELLOW
BLACK
GREEN
WHITE
RED
TAPE POLYTETRAFLUOROETHYLENE
FIGURE 1. Cable configuration.
*The complete Part or Identifying Number (PIN) requires a color code designator (see table I).
AMSC N/A
FSC 6145
