MIL-DTL-27072/25D
TABLE I. Construction data.
Basic wire except color
(reference)
Finished
SAE AS22579/11-20*
cable
or NEMA HP3EWBGE*
diameter
PIN M27072/25
in. (mm)
Nominal
Wire
Number of
±10% 1/
Strand size
diameter
size
strands
inch (mm) 1/
(AWG)
JDDA*
20
19
32
.058 (1.47)
.197 (5.00)
Asterisks (*) shall be replaced by the appropriate color designator.
1/ Dimensions are in inches. Metric equivalents are provided for information purposes only.
Marginal notations are not used in this revision to identify changes with respect to the previous issues due
to the extensiveness of the changes.
Referenced document. This document references MIL-DTL-27072.
CONCLUDING MATERIAL
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - SH
Air Force - 11
(Project 6145-2006-017)
DLA - CC
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organization and responsibilities can change, please verify the currency of the information above using
the ASSIST Online database at https://assist.daps.dla.mil.
3
