MIL-DTL-25038J
1.2.2 Color. The insulation color is identified by a series of numbers. The first number is the color of
the insulation; the second number represents the color of the first stripe or band; the third number, the
color of the second stripe or band, and so on. The colors and their corresponding numbers are shown in
TABLE I. Color code.
Number designator
Color
Number
Color
designator
0
Black
5
Green
1
Brown
6
Blue
2
Red
7
Violet
(purple)
3
Orange
8
Gray (slate)
4
Yellow
9
White
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this
specification. This section does not include documents cited in other sections of this specification or
recommended for additional information or as examples. While every effort has been made to ensure the
completeness of this list, document users are cautioned that they must meet all specified requirements
documents cited in sections 3, 4, or 5 of this specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards and handbooks. The following specifications, standards and
handbooks form a part of this document to the extent specified herein. Unless otherwise specified, the
issues of these documents are those cited in the solicitation or contract (see 6.2).
FEDERAL STANDARD
-
Cable and Wire, Insulated; Methods of Testing
FED-STD-228
DEPARTMENT OF DEFENSE SPECIFICATIONS
MIL-PRF-5606
-
Hydraulic Fluid, Petroleum Base: Aircraft, Missile, and Ordnance
MIL-DTL-5624
-
Turbine Fuel, Aviation, Grades JP-4 and JP-5
MIL-PRF-7808
-
Lubricating Oil, Aircraft Turbine Engine, Synthetic Base
MIL-DTL-12468
-
Decontaminating Agent, STB
MIL-PRF-23699
-
Lubricating Oil, Aircraft Turbine Engine, Synthetic Base, NATO
Code O-156
MIL-DTL-25038/1
-
Wire, Electrical, High Temperature, Fire Resistant, Flight Critical,
Normal Weight
MIL-DTL-25038/3
-
Wire, Electrical, High Temperature, Fire Resistant, Flight Critical,
Light Weight, Small Diameter
2
