MIL-DTL-25038J
4.4 Conformance inspection. Conformance inspection shall consist of and be in accordance with the
group A and B inspections specified in 4.4.1 and 4.4.2 respectively. Conformance inspection shall be
performed on every lot of wire produced under this specification. (see 4.3.2).
4.4.1 Group A inspection. Group A inspection shall consist of the inspections specified in group A of
table III.
4.4.2 Group B inspection. Group B inspections shall consist of the tests specified in group B of table
III on a sampling basis. The sample shall be selected from inspection lots that have passed group A
inspection.
4.4.2.1 Sampling. A random sample shall be selected from each inspection lot in accordance with
table IV. The sample size shall be based on the inspection lot size.
TABLE IV. Inspection sample.
1/
Inspection lot size
Sample size
1
1
2 to 8
2
9 to 90
3
91 to 150
12
151 to 300
19
1/ Lot size is based on the number of units of product (reels,
4.4.3 Specimen length. Each specimen for inspection shall be of the length specified in the
applicable test method.
4.4.4 Rejected lots. Failure of any sample to pass conformance inspections shall constitute a failure
of the lot. If an inspection lot is rejected, the manufacturer may rework the lot to correct the defects or
screen out the defective units, and resubmit the lot for re-inspection. Such lots shall be separated from
new lots and shall be identified as re-inspected lots.
4.4.5 Noncompliance. If a sample fails to pass conformance inspections, the manufacturer should
notify the cognizant inspection activity of such failure and take corrective action on the materials,
processes, or both, as warranted, on all units of the product. Acceptance and shipment of the product will
be discontinued until corrective action acceptable to the inspection activity has been taken. After the
corrective action has been taken, the conformance inspection shall be repeated on replacement articles.
(This includes all test and examinations, or only the test that the original sample failed, at the option of the
inspection activity.) Final acceptance and shipment will be withheld until the conformance inspection has
shown that the corrective action was successful. In the event of failure after re-inspection, information
concerning the failure should be provided to the cognizant inspection activity.
4.5 Interpretation of terms. Terms and definitions used for sampling and inspections herein shall be
in accordance with the following:
4.5.1 Inspection lot. An inspection lot shall consist of all wire of the same PIN, produced under
essentially the same conditions on the same machine presented for inspection and shipment at one time.
For this specification, an inspection lot shall not exceed 300 units of product.
4.5.2 Unit of product. The unit of product for determining lot size under this specification shall be the
quantity of continuous length of wire on one coil, reel, or spool, as applicable.
10
