MIL-DTL-24643/18F
TABLE I. Details (unshielded).
Overall diameter
Jacket
Military part no.
No. of
thickness min.
Type and size
min.
max.
M24643/18
conductors
avg. (inch)
(inch)
(inch)
-01UN
LSMSCU-7
7
0.040
0.447
0.484
-02UN
LSMSCU-10
10
0.050
0.575
0.622
-03UN
LSMSCU-14
14
0.050
0.617
0.668
-04UN
LSMSCU-19
19
0.050
0.682
0.738
-05UN
LSMSCU-24
24
0.050
0.790
0.855
-06UN
LSMSCU-30
30
0.050
0.833
0.901
-07UN
LSMSCU-37
37
0.060
0.926
1.002
-08UN
LSMSCU-44
44
0.060
1.030
1.114
-09UN
LSMSCU-61
61
0.060
1.156
1.250
-10UN
LSMSCU-91
91
0.060
1.369
1.480
TABLE II. Details (shielded).
Overall diameter
Jacket
(inches)
No. of
Military part no.
thickness min.
Type and size
conductors
M24643/18
min.
max.
avg. (inch)
(inch)
(inch)
-01UD
LSMSCS-7
7
0.040
0.507
0.544
-02UD
LSMSCS-10
10
0.050
0.635
0.682
-03UD
LSMSCS-14
14
0.050
0.677
0.728
-04UD
LSMSCS-19
19
0.050
0.742
0.798
-05UD
LSMSCS-24
24
0.050
0.850
0.915
-06UD
LSMSCS-30
30
0.050
0.893
0.961
-07UD
LSMSCS-37
37
0.060
0.986
1.065
-08UD
LSMSCS-44
44
0.060
1.090
1.174
-09UD
LSMSCS-61
61
0.060
1.216
1.310
-10UD
LSMSCS-91
91
0.060
1.429
1.540
REQUIREMENTS:
Qualification required.
INSPECTION:
Basic Electricals:
Conductor resistance (ohms/1000 feet at 25 °C, max.)
7.07
Voltage withstand (volts, root mean square, min.)
Conductor to conductor
3000
Conductor to shield (Type LSMSCS only)
1500
