MIL-DTL-23806B
4.4.1.2.3 Defective unit. A defective unit is any sample unit failing any test in any test group. The reel
of cable from which the sample unit was taken shall be considered defective.
4.4.1.2.4 Rejected lots. If an inspection lot is rejected, the supplier may rework it to correct the defects,
or screen out the defective units, and resubmit for re-inspection. Such lots shall be separate from new
lots, and shall be clearly identified as re-inspected lots.
4.4.1.2.5 Disposition of sample units. Sample units, and the reels of cable from which the sample units
were taken which failed one or more inspections shall not be delivered on the contract or order. However,
insulation defects, spark failures may be repaired or the cable cut at this point (see 4.5.2), and shipped.
4.4.1.3 Group B inspection. Group B inspection shall consist of the examinations and test specified in
table IV, in the order shown, and shall be made on reels of cable which have been subjected to and have
passed the group A inspection.
4.4.1.3.1 Sampling plan. The sampling plan shall be specified in table III.
TABLE IV. Group B inspection.
Examination or test
Requirement
Test
paragraph
paragraph
Attenuation 1/
Impedance
Capacitance
Velocity of propagation
VSWR
Flaring
1/ At all specified frequencies.
4.4.1.3.2 Sample unit. A sample unit is a piece of cable cut from the reel of cable and the length
specified for the applicable test method.
4.4.1.3.3 Defective unit. A defective unit is any sample unit failing any test or inspection in table IV.
The reel of cable from which the sample unit was taken will be considered defective.
4.4.1.3.4 Rejected lots. If an inspection lot is rejected, the supplier may rework it to correct the
defect(s), or screen out the defective units, and resubmit for re-inspection. Such lots shall be kept
separate from new lots, and shall be clearly identified as re-inspected lots.
4.4.1.3.5 Disposition of sample units. Sample units and the reels of cable from which the sample units
were taken may be delivered on the contract or order, if the sample unit(s) have passed all the group B
inspection and the lot was accepted.
4.4.1.4 Periodic inspection. Periodic inspection shall consist of group C inspection.
4.4.1.4.1 Group C inspection. Group C inspection shall consist of the examinations and tests specified
in table V, in the order shown. Group C inspection shall be made on sample units selected from
inspection lots which have passed the groups A and B inspection.
7
