INCH-POUND
MIL-DTL-23806B
22 February 2007
SUPERSEDING
MIL-C-23806A(EC)
23 June 1969
DETAIL SPECIFICATION
CABLE, RADIO FREQUENCY, COAXIAL, SEMIRIGID,
FOAM DIELECTRIC
GENERAL SPECIFICATION FOR
Inactive for new design after 10 July 2000
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers foam dielectric, coaxial semirigid radio frequency cables with smooth
outer conductors (see 6.1).
1.2 Classification. The cable covered under this specification is to be furnished in the following types, sizes,
1.2.1 Types. Cable will be of the following type(s);
Type I Unjacketed
Type II Jacketed (polyethylene)
1.2.2 Sizes. Cable is to conform to the following outside diameters (exclusive of jacket);
.500 inch, nominal
.875 inch, nominal
1.2.3 Impedance. Impedances will be 50 or 75 ohms.
1.2.4 Type designation. The type designation is derived from the "RG-XXX/U" nomenclature as specified
1.2.5 Part or Identifying Number (PIN). The PIN consists of the applicable "RG" designation (see 6.2).
RG
-
XXX
/U
Component
Number
Basic indicator
(see 1.2.5.1)
(see 1.2.5.2)
(see 1.2.5.3)
