MIL-DTL-17/211A
TABLE I. Description Continued.
Barrier tape
A .001 inch thick polyester tape faced with a
.002 inch thick layer of aluminum. The tape
will be applied with a 50% lap, minimum.
Aluminum face toward the outer conductor.
Diameter: .350 inch, maximum.
Jacket
Type XIV, Cross-linked polyolefin
Diameter: .405 inch +.010.
Armor
Single braid of aluminum-alloy wire.
M17/211-00002 and
Diameter: .475 inch, maximum.
M17/211-00004
ENGINEERING INFORMATION:
Continuous working voltage: 3,700 V rms, maximum.
Operating frequency: 1 GHz, maximum.
Velocity of propagation: 62 percent, nominal.
Operating temperature range: -30 to +85C.
Inner conductor properties:
DC resistance, maximum, at 20C: 0.65 ohms per 100 feet.
Elongation: 15 percent, minimum.
2
Tensile strength: 60 klbf/inch , minimum.
Engineering notes: This cable useful in applications where electrical noise generated within the coaxial cable, due to flexure or
vibration, must be limited..
REQUIREMENTS:
Dimensions, configuration and description: See figure 1 and table I.
Environmental and mechanical:
Visual and mechanical examination: Applicable.
Adhesion of conductors:
Inner conductor to core: 7 pounds, minimum; 50 pounds maximum.
Aging stability: +98 2C.
Stress crack resistance: Not applicable.
Outer conductor integrity: Not applicable.
Cold bend: -40C 2C.
Dimensional stability: +85C 2C.
Inner conductor from core: 0.062 inch, maximum.
Inner conductor from jacket: .125 inch, maximum.
Contamination: Not applicable.
2
