MIL-DTL-17/210A
Structural return loss: See figure 3.
Capacitance: 32.2 pF per foot, maximum.
Capacitance unbalance: Not applicable.
Transmission unbalance: Not applicable.
Mechanically induced noise: Not applicable.
Time delay: Not applicable.
Frequency MHz
Attenuation dB
Power watts
50
.65
6500
100
1.00
5000
1000
5.00
750
5600
28.00
200
Maximum power - - - - - at 25°C sea level.
Maximum attenuation - - - - - - - - - - - - - -
FIGURE 2. Power rating at 25°C sea level.
4
