MIL-DTL-17/192D
Watertightness (Applicable to M17/192-00003, only): One end of a five foot length of completed cable
shall be placed in a terminal fitting which will allow water pressure to be applied directly to the exposed
cross-sectional area of the end of the cable. Exposure of the sides of the cable to water shall be kept to a
minimum, and the fitting shall not exert radial compression against the cable. Unless otherwise approved
by the qualifying activity, the sealer used for the packing gland in the terminal fitting shall be a metal alloy
having a maximum melting point of 88°C. The specimen shall be subjected to a water pressure of
25 lbf /in2 for a period of 6 hours. Any evidence of water leakage shall be cause for rejection.
Hydrostatic (open end) (Applicable to M17/192-00003, only): A 5-foot specimen of completed cable shall
be fitted into a gland similar to USL 44500B-12. The cable shall be capable of withstanding 1,000 lbf/in2
applied to the gland end of the specimen for a period of 2 hours. Any evidence of water leakage shall be
cause for rejection.
Electrical:
Continuity: Applicable.
Spark test: 8,000 V rms, minimum.
Voltage withstanding: 12,000 V rms, minimum
Insulation resistance: Not applicable.
Corona extinction voltage: 7,000 V rms, minimum.
Characteristic impedance: 50 ohms ± 2.
Attenuation: See figure 2.
Structural return loss: See figure 3.
Capacitance: 32.2 pF per foot, maximum.
Capacitance stability: Not applicable.
Capacitance unbalance: Not applicable.
Transmission unbalance: Not applicable.
Mechanically induced noise voltage: Not applicable.
Time delay: Not applicable.
Part or Identifying Number (PIN): See table II.
TABLE II. Cross-reference of PIN.
PIN
Type
M17/192-00001
Low smoke
M17/192-00002
Low smoke, temperature
stabilized
M17/192-00003
Low smoke, water blocked
5
