MIL-DTL-17/192D
TABLE I. Description. 1/
Component
Construction
Inner conductor
Solid bare copper wire.
Diameter: .106 inch ±0.001
Dielectric core
Type A-I: Solid polyethylene
Diameter: .370 inch ± 0.010
Double braid of AWG No. 33, bare copper wire.
Outer conductor
Diameter: .445 inch, maximum.
Coverage: 94.8% nominal
Inner braid
Carriers:
24
Ends:
10
Picks/inch: 5.4 +10%
Outer braid
Coverage: 93.6% nominal
Carriers:
24
Ends:
8
Picks/inch: 10.6 +10%
Barrier tape
A .001 inch thick polyester tape faced with a .002 inch
thick layer of aluminum. The tape will be applied with a
50% overlap. Aluminum face toward the outer conductor.
Diameter: .455 inch maximum.
Jacket
Cross linked polyolefin.
Diameter: .545 inch +.010
1/ Free strippable blocking compound needed where necessary to meet hydrostatic test. The inner shield
may be partially imbedded in the dielectric. Applicable to water blocked cables only.
ENGINEERING INFORMATION
Continuous working voltage: 5,200 V rms, maximum.
Operating frequency: 1 GHz, maximum.
Velocity of propagation: 65.9 percent, nominal.
General configuration: See figure 1.
Power rating: See figure 2.
Operating temperature range: -30°C to +85°C
Inner conductor properties:
DC resistance (maximum at 20°C): 0.0941 ohm per 100 feet.
Elongation: 25 percent, minimum.
Tensile strength: Not applicable.
