MIL-DTL-17/134D
Electrical:
Continuity: Applicable.
Spark test: 5,000 V rms, +10%, -0%.
Voltage withstanding: 5,000 V rms, minimum applied between the inner and outer conductors with
the outer conductor grounded; 500 V dc minimum applied between the outer conductor and the extra
shield with the extra shield grounded.
Insulation resistance: Not applicable.
Corona extinction voltage: 1,900 V rms, minimum.
Characteristic impedance: 50 ohms ± 2.
Attenuation: See figure 2.
Structural return loss: See figure 3.
Capacitance: 32.2 pF per foot, maximum.
Capacitance stability: Not applicable.
Capacitance unbalance: Not applicable.
Transmission unbalance: Not applicable.
Mechanically induced noise voltage: Not applicable.
Time delay: Not applicable.
Part or Identifying Number (PIN): See table II.
Supersession data: See table II.
TABLE II. Cross-reference of PIN.
PIN
Superseded PIN
Type
type or designation
M17/134--00001 1/
TRF58
Water blocked
M17/134--00002 1/
YR19210
Non-water blocked
M17/134--00003 2/
AA-7557
Water blocked
M17/134--00004 2/
AA-7558
Non-water blocked
1/ Inactive for new design.
2/ Cable previously manufactured using the barrier tape is
acceptable for Government use until stock is purged.
Changes from previous issue. Marginal notations are not used in this revision to identify changes with
respect to the previous issue due to the extent of the changes.
