MIL-DTL-17/133F
Standing
Reflection
Return
Wave
coefficient
loss dB
Ratio
17.3910
.8913
1
8.7242
.7943
2
5.8480
.7079
3
4.4194
.6310
4
3.5698
.5623
5
3.0095
.5012
6
7
2.6146
.4467
8
2.3229
.3981
9
2.0998
.3548
10
1.9250
.3162
11
1.7849
.2818
12
1.6709
.2512
13
1.5769
.2239
14
1.4985
.1995
15
1.4326
.1778
16
1.3767
.1585
17
1.3290
.1413
18
1.2000
.1259
19
1.2528
.1122
20
1.2222
.1000
21
1.1957
.0891
22
1.1726
.0794
23
1.1524
.0708
24
1.1347
.0631
25
1.1192
.0562
26
1.1065
.0501
27
1.0725
.0447
28
1.0829
.0398
29
1.0738
.0356
30
1.0653
.0316
FIGURE 3. Minimum structural return loss cable Continued.
