MIL-DTL-17/130F
Maximum attenuation
(Test requirements shall be as noted as line indicates on graph)
Maximum power
At 25°C at sea level.
Attenuation
Power
1. M17/130-RG402, -00001, -00004, -00005 and -
dB
dB
Watts
00012
MHz
1
2
At 1.5 SWR
2. M17/130-00002, -00003, -00006, -00007, -00010,
500
8
14
600
-00011 and -00013
1000
12
19
450
3000
21
31
250
5000
180
29
39
10000
45
52
120
20000
70
70
70
FIGURE 2. Power rating and attenuation.
5
