MIL-DTL-17/130F
TABLE I. Description Continued.
PIN
Inner conductor
Dielectric core
Outer conductor 1/
Solid, silver-coated
Copper tubing, diameter .141 +.002, -.001
copper-clad steel
inch, silver plated in accordance with ASTM
M17/130-00012
Same as above
diameter .0362 ± .0007
B700, type 2, grade A, 300µ inches
minimum. 3/
inch.
Copper tubing, diameter .141 +.002, -.001
.0362 ±.0007 inch
inch, silver plated in accordance with ASTM
M17/130-00013
Same as above
B700, type 2, grade A, 300µ inches
diameter. 4/
minimum. 3/
Solid, silver-coated
Copper tubing, diameter .141 +.002, -.001
copper-clad steel
inch. 90/10 tin plated in accordance with
M17/130-00014
Same as above
diameter .0362 ± .0007
SAE-AMS-P-81728, .0003 inch, thick
minimum.
inch.
Solid silver coated
Same as above
Same as above
M17/130-00015
copper wire, diameter
.0362 ±.0007 inch.
1/ Welded outer conductor in accordance with ASTM B447 and MIL-DTL-17 is optional.
2/ Hard outer conductor required, 33,000 psi, minimum, 30 percent elongation, maximum.
3/ The outer diameter dimension is after plating.
4/ Nickel-coated, copper-clad steel wire, conforming to ASTM B559, class N 40 HS two percent,
with uniform and continuous silver coating, 40 microinches minimum thick. Wire shall be drawn to final
size after plating.
5/ Tensile strength (outer conductor): 35,000 inch2-pounds maximum, 40 percent elongation minimum
measured over two inches.
6/ These PIN's are for soft outer conductor cables only.
7/ The tensile strength (outer conductor) shall be 15,000 psi, maximum, 40 percent elongation minimum
measured over 2 inches.
ENGINEERING INFORMATION:
Continuous working voltage: 1,900 V rms, maximum.
Operating frequency: 20 GHz, maximum.
Velocity of propagation: 69.5 percent, nominal.
Power rating: See figures 2 and 3.
Operating temperature range: -40ºC to + 125ºC.
