MIL-DTL-13169 Wire, Electrical \(For Instrument Test Leads\)This specification covers one type of single-conductor, AWG No 18, stranded, electrical wire, insulated for voltages up to and including 1,000 volts root mean square \(rms\) with Buna-S compound. Wire covered by this specification is classified as type TL-G. This wire is primarily intended for use as instrument test leads.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9


. . . . . . . . . . . . . . . . . . . . . . . . . . .
MIL-DTL-13169E
3.4.4 Continuity. The finished wire shall have continuous continuity.
3.5 Workmanship. The wire shall be uniform in quality and free from defects that affect performance,
serviceability, or appearance, such as lumps, kinks, splits, abrasions, scrapes, corroded surfaces, and
skin impurities.
4. VERIFICATION
4.1 Classification of inspections. The inspection requirements specified herein are classified as
follows:
Conformance inspection (see 4.2).
4.2 Conformance inspection. Conformance inspection shall consist of the inspections listed for
groups A, B, and C inspection in tables II, III, and IV, respectively. Unless otherwise specified,
conformance inspection shall be performed on every lot of wire procured under this specification
(see 6.2).
TABLE II. Group A inspection.
Inspection
Requirement
Verification
Visual
Materials
Copper strand
Separator
Insulation compound
Construction
Conductor
Workmanship
Performance
Insulation flaws
Continuity
TABLE III. Group B inspection.
Inspection
Requirement
Verification
Insulation thickness
Outside diameter
Unaged physical property
Tensile strength
Elongation
Set
Dielectric strength
Insulation resistance
4
