MIL-DTL-915/1F
Assembly
First
- Three insulated conductors cabled with a lay not greater than l4 inches. The
uninsulated conductor shall be placed in one valley. Fibrous fillers shall be
used in all valleys as necessary to form a round cable.
Second - Rubber filled cotton tape binder.
Third
- Polychloroprene jacket. Nominal wall thickness 0.125 inch.
TABLE I. Details.
Overall diameter
Conductors
maximum (inches)
Type and size
Number
AWG Size
CVSF-4
3
3 (class K)
1.45
1
5 (class K)
EXAMINATION AND TESTS:
Requirements
Basic electrical:
Conductor resistance - ohms/1000 feet at 25°C, maximum
AWG No. 3 ........................................................................................................................ 0.215
AWG No. 5 ........................................................................................................................ 0.339
Voltage withstand - volts, root mean square, ................................................................................. 2500
Insulation resistance megohms-1000 feet, minimum
Conductor to conductor and conductor to water..................................................................150
Group A:
Visual and dimensional .......................................................................................................... No failure
Group B:
Physicals (unaged)
Insulation (conductor)
Tensile strength - lbf/in2, minimum ......................................................................... 600
Elongation - percent, minimum ............................................................................... 225
Jacket (cable)
Tensile strength - lbf/in2, minimum ....................................................................... 1800
Elongation - percent, minimum ............................................................................... 350
Bending endurance - 4 inches maximum diameter roller, at minus 30 ± 2°C,
cycles, minimum...................................................................................................................500
2
