MIL-DTL-442G
4.4.9.4 Ozone resistance. This test shall be performed in accordance with the ozone resistance test
in accordance with ASTM-D1149 except as indicated below for ozone concentration and test
temperature.
4.4.9.5 Chamber environment. The ozone concentration used in this test shall be 50+3 parts of
9
ozone per 1x 10 parts of air. .
4.4.10 Visual and mechanical examination. Finished cable shall be examined to determine that the
materials, physical dimensions, construction, and workmanship are in accordance with the applicable
requirements.
5. PACKAGING
5.1 Packaging. For acquisition purposes, the packaging requirements shall be as specified in the
contract or order (see 6.2). When packaging of materiel is to be performed by DoD or in-house contractor
personnel, these personnel need to contact the responsible packaging activity to ascertain packaging
requirements. Packaging requirements are maintained by the Inventory Control Point's packaging
activities within the Military Service or Defense Agency, or within the military service's system commands.
Packaging data retrieval is available from the managing Military Department's or Defense Agency's
automated packaging files, CD-ROM products, or by contacting the responsible packaging activity.
6. NOTES
(This section contains information of a general or explanatory nature that may be helpful, but is not
mandatory.)
6.1 Intended use. Cables covered by this specification are intended for use as shown in table VIII.
The cables covered by this specification are defense unique because they must fire explosives and
operate rockets under rugged, high temperature and humidity battlefield conditions not typically found in
commercial operations.
TABLE VIII. Cross reference of intended use for type and class of cable.
Intended use
Type
Class
AWG
Lead wire in firing explosive charges electrically
I
1
20
in demolition operations
II, III
1
18
Rocket connectors
II
2
22, 20
General defense application where voltage does
I, II
1, 2, 3
20, 18
not exceed 300 volts
6.2 Acquisition requirements. Acquisition documents should specify the following:
a. Title, number, and date of this specification.
type II, include tin coating if required (see 3.2.1.1).
d. The quantity required (length, number of reels, etc.).
10
