INCH-POUND
MIL-DTL-29606A
05 October 2010
SUPERSEDING
MIL-W-29606
30 August 1994
DETAIL SPECIFICATION
WIRE, ELECTRICAL, STRANDED, UNINSULATED COPPER,
COPPER ALLOY, OR ALUMINUM, OR THERMOCOUPLE EXTENSION,
GENERAL SPECIFICATION FOR
This specification is approved for use by all Departments and Agencies of the Department of
Defense.
1.
SCOPE
1.1 Scope. This specification covers concentric lay stranded and rope-lay stranded round
electrical conductor fabricated from copper, copper alloy or aluminum. This specification also
covers thermocouple extension conductor fabricated from nickel/chromium or
nickel/aluminum/manganese. The conductors in this specification are suitable for use in
insulated wires used in aerospace and other applications.
1.2 Classification. Stranded conductors are classified herein. The classifications are as
follows:
Conductor Material
Conductor Stranding
Conductor Coating
Conductor Dimensions
1.2.1 Part or Identifying Number (PIN). PINS to be used for the wire acquired to this
specification are created as follows:
M29606
-
20
-
SCC
-
GP
Basic Part No.
Conductor
Conductor
Conductor
(1.2.1.1)
Size
Material and
Diameter
(1.2.1.2)
Coating
Tolerance
(1.2.1.3)
(1.2.1.4)
Comments, suggestions, or questions on this document should be addressed to: Naval Air Systems
Command (Commander, Naval Air Warfare Center Aircraft Division, Code 4L8000B120-3,
Highway 547, Lakehurst, NJ 08733-5100) or emailed to michael.sikora@navy.mil. Since contact
information can change, you may want to verify the currency of this address information using the
ASSIST online database at https://assist.daps.dla.mil/.
AMSC N/A
FSC 6145
