MIL-DTL-28830/5E
M28830/5-II (old design)
M28830/5-II-A (new design)
M28830/5-IV (old design)
ATTENUATION
AVERAGE POWER
dB/100 Ft.
(Kilowatts)
Standard conditions for average power and attenuation:
Attenuation
Frequency
(dB)
(MHz)
For average power:
400
0.43
VSWR: 1.0
Ambient temperature: 40°C
1,000
0.73
Inner conductor temperature: 100°C
2,000
1.11
For attenuation:
VSWR: 1.0
Ambient temperature: 24°C
FIGURE 2. Attenuation and power.
3
