MIL-DTL-28781E
TABLE I. Color coding.
Pair
Pair
Color
Color
number
number
1
Blue and white (or natural)
27
Orange-white (stripe) and white (or natural)
2
Orange and white (or natural)
28
Green-white (stripe) and white (or natural)
3
Green and white (or natural)
29
Brown-white (stripe) and white (or natural)
4
Brown and white (or natural)
30
Slate-white (stripe) and white (or natural)
5
Slate and white (or natural)
31
Blue-white (stripe) and red
6
Blue and red
32
Orange-white (stripe) and red
7
Orange and red
33
Green-white (stripe) and red
8
Green and red
34
Brown-white (stripe) and red
9
Brown and red
35
Slate-white (stripe) and red
10
Slate and red
36
Blue-white (stripe) and black
11
Blue and black
37
Orange-white (stripe) and black
12
Orange and black
38
Green-white (stripe) and black
13
Green and black
39
Brown-white (stripe) and black
14
Brown and black
40
Slate-white (stripe) and black
15
Slate and black
41
Blue-white (stripe) and yellow
16
Blue and yellow
42
Orange-white (stripe) and yellow
17
Orange and yellow
43
Green-white (stripe) and yellow
18
Green and yellow
44
Brown-white (stripe) and yellow
19
Brown and yellow
45
Slate-white (stripe) and yellow
1/
46
20
Slate and yellow
Blue-white (stripe) and violet
Blue and violet
47
Orange-white (stripe) and violet
21
22
Orange and violet
48
Green-white (stripe) and violet
23
Green and violet
49
Brown-white (stripe) and violet
24
Brown and violet
50
Slate-white (stripe) and violet
25
Slate and violet
51
Red and white (or natural)
1/
Spare
26
Blue-white (stripe) and
Red and Black
White (or natural)
(For 52
or 104
pair)
1/ At the manufacturer's option, pair number 46 and the spare pair may be used to assure the required
number of (non-defective) pairs.
3.2.2.3.1 Color standards. The colored insulation shall match the centroid colors of table II, within
the limits of standards for colors as specified in Munsell Color Charts for Plastic Cable and Wire. The
color pigments shall be chosen to yield uniform dielectric constant between colors and shall have no
deteriorating effects on the insulation.
