INCH-POUND
MIL-DTL-27072/83C
12 March 2012
SUPERSEDING
MIL-DTL-27072/83B
8 December 2000
DETAIL SPECIFICATION SHEET
CABLE, SPECIAL PURPOSE, ELECTRICAL, MULTICONDUCTOR
(7 CONDUCTORS) AND SINGLE SHIELDED,
M27072/83MACA*
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-27072.
REQUIREMENTS:
SHEATH POLYVINYL CHLORIDE
SHIELD TINNED COPPER
WHITE
/BLACK
TAPE
WHITE
WHITE
/VIOLET
/BROWN
WHITE
/BLUE
WHITE
WHITE
/RED
/GREEN
WHITE
/ORANGE
NOTE: The complete Part or Identifying Number (PIN) requires a color code designator (see table I).
FIGURE 1. Cable configuration.
AMSC N/A
FSC 6145
