INCH-POUND
MIL-DTL-27072/76C
12 March 2012
SUPERSEDING
MIL-DTL-27072/76B
8 December 2000
DETAIL SPECIFICATION SHEET
CABLE, SPECIAL PURPOSE, ELECTRICAL, MULTICONDUCTOR
(1 SHIELDED PAIR AND 8 WIRES UNDER A DOUBLE SHIELD),
M27072/76SACA*
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-27072.
REQUIREMENTS:
SHEATH POLYVINYL CHLORIDE
SHIELD NO. 1
TINNED COPPER
TAPE POLYESTER
SHIELD NO. 2
WHITE
TINNED COPPER
/BROWN
WHITE
WHITE
/RED
/GRAY
WHITE
/BLACK
WHITE
WHITE
/ORANGE
/VIOLET
WHITE
JACKET
WHITE
WHITE
/YELLOW
/BLUE
WHITE
/GREEN
SHIELD NO. 3
TINNED COPPER
NOTE: The complete Part or Identifying Number (PIN) requires a color code designator (see table I).
FIGURE 1. Cable configuration.
AMSC N/A
FSC 6145
