MIL-DTL-24643/7F
TABLE I. Details.
Overall diameter
Military part no.
Number of
Type and size
Min.
Max.
M24643/7
conductors
(inch)
(inch)
-01UN
LSMHOF-7
7
0.465
0.500
-02UN
LSMHOF-10
10
0.540
0.585
-03UN
LSMHOF-14
14
0.585
0.635
-04UN
LSMHOF-19
19
0.650
0.705
-05UN
LSMHOF-24
24
0.735
0.795
-06UN
LSMHOF-30
30
0.775
0.835
-07UN
LSMHOF-37
37
0.855
0.925
-08UN
LSMHOF-44
44
0.925
1.000
-09UN
LSMHOF-61
61
1.100
1.175
REQUIREMENTS:
Qualification required.
INSPECTION:
Basic Electricals:
Conductor resistance (ohms/1000 feet at 25 °C, max.)
4.59
Voltage withstand (volts, root mean square, min.)
Conductor to conductor
2000
Insulation resistance (megohms/1000 feet, min.)
Conductor to conductor
500
Conductor continuity
No failure
Group A:
Visual and dimensional
No failure
Group B:
Thermoset proof test (percent, max.)
Insulation
50
Jacket (when tested at 200 °C)
50
Twisting and bending endurance (see table I for roller size)
At 75 °C (cycles, min.)
6000
At minus 30±2 °C (cycles, min.)
2000
Physicals (unaged)
Insulation (extruded)
2
