MIL-DTL-24643/38F
Fourth
-
Group covering of two polyester tapes, outer tape sealed. An alternate shield insulation
may consist of one polyester tape, plus an extruded jacket of a suitable transparent
material, minimum average thickness of the transparent material 0.003 inch. The
standard identification code shall be applied by Method 2.
Assembly
First
Five pairs cabled to form a core. Three pairs and eight groups of seven cabled over the
-
core, with a lay in accordance with 3.4.4 of MIL-DTL-24643. Pair no. 1 through 5 in
core; the sequence of the outer layer pair no. 6; groups no. 1, 2 and 3: pair no. 7: groups
no. 4, 5 and 6: pair no. 8: groups no. 7 and 8. Fillers may be used as necessary to form a
firm, well-rounded assembly.
Second
-
An optional binder.
Cross-linked polyolefin jacket (see table I for jacket thickness).
Third
-
TABLE I. Details.
Overall diameter
Cable jacket
Military part no.
Number of pairs /
Type
thickness min.
min.
max.
M24643/38
number of conductors
avg. (inch)
(inch)
(inch)
-01UN
LSECM
8/56
0.075
1.290
1.370
REQUIREMENTS:
Qualification required.
INSPECTION:
Basic Electricals:
Conductor resistance (ohms/1000 feet at 25 °C, max.)
ASTM B286, Size 20-7
11.03
18 AWG, Class B
7.47
Voltage withstand (volts, root mean square, min.)
Conductor to conductor
2000
Conductor to shield (pairs only)
1000
Component shield to component shield
500
Insulation resistance (megohms/1000 feet, min.)
Conductor to conductor
500
Conductor to shield (pairs only)
500
Component shield to component shield
100
Conductor continuity
No failure
Shield continuity
No failure
