MIL-DTL-24643/37F
TABLE I. Details.
Overall diameter
Cable jacket
Military part no.
Number of
thickness min.
Type and size
min.
max.
M24643/37
triads
avg. (inch)
(inch)
(inch)
-01UN
LS3U-3
3
0.040
0.580
0.620
-02UN
LS3U-7
7
0.040
0.760
0.810
-03UN
LS3U-12
12
0.050
1.030
1.090
REQUIREMENTS:
Qualification required.
INSPECTION:
Basic Electricals:
Conductor resistance (ohms/1000 feet at 25 °C, max.)
7.06
Voltage withstand (volts, root mean square, min.)
Conductor to conductor
2000
Insulation resistance (megohms/1000 feet, min.)
Conductor to conductor
500
Conductor continuity
No failure
Group A:
Visual and dimensional
No failure
Capacitance
Mutual capacitance, 1 kilohertz (KHz) (pF/ft, max.)
30
Capacitance unbalanced (percent max.)
8
Group B:
Thermoset proof test (percent, max.)
Insulation
50
Jacket (when tested at 200 °C)
50
Physicals (unaged)
Insulation (extruded)
Tensile strength (lb/in2, min.)
700
Elongation (percent, min.)
150
Jacket (cable)
Tensile strength (lb/in2, min.)
1300
Elongation (percent, min.)
160
2
