MIL-DTL-24643/36F
Construction, Variant for Type LS3SWU
Cross-linked polyolefin jacket (see table I for thickness).
Tenth
-
Construction, Variant for Type LS3SWUS
Tenth
-
Braided shield of tin-coated copper with a minimum coverage of 85 percent.
Eleventh
-
Spirally-wrapped 0.002-inch thick polyethylene terephthalate (polyester film) separator
tape with 25 percent minimum overlap.
Twelfth
-
Braided shield of tin-coated copper with a minimum coverage of 85 percent.
Thirteenth
-
An optional binder.
Cross-linked polyolefin jacket (see table I for thickness).
Fourteenth
-
TABLE I. Details.
Overall diameter
Cable jacket
Number of
Military part no.
thickness min.
Type and size
min.
max.
triads
M24643/36
avg. (inch)
(inch)
(inch)
-01UN
LS3SWU-3
3
0.040
0.610
0.655
-01UD
LS3SWUS-3
3
0.040
0.675
0.710
-02UN
LS3SWU-7
7
0.040
0.880
0.940
-02UD
LS3SWUS-7
7
0.040
0.940
1.000
-03UN
LS3SWU-10
10
0.050
1.100
1.180
-03UD
LS3SWUS-10
10
0.050
1.160
1.240
-04UN
LS3SWU-14
14
0.050
1.200
1.280
-04UD
LS3SWUS-14
14
0.050
1.260
1.340
-05UN
LS3SWU-19
19
0.050
1.370
1.450
-05UD
LS3SWUS-19
19
0.050
1.430
1.510
-06UN
LS3SWU-24
24
0.050
1.640
1.760
-06UD
LS3SWUS-24
24
0.050
1.700
1.820
-07UN
LS3SWU-30
30
0.050
1.760
1.860
-07UD
LS3SWUS-30
30
0.050
1.820
1.920
-08UN
LS3SWU-37
37
0.060
1.890
1.940
-08UD
LS3SWUS-37
37
0.060
1.950
2.050
-09UN
LS3SWU-44
44
0.060
2.140
2.240
-09UD
LS3SWUS-44
44
0.060
2.200
2.300
REQUIREMENTS:
Qualification required.
INSPECTION:
Basic Electricals:
Conductor resistance (ohms/1000 feet at 25 °C, max.)
7.06
2
