MIL-DTL-24643/35D
Construction, Variant Type LS3SU
Cross-linked polyolefin jacket (see table I for thickness).
Tenth
-
Construction, Variant Type LS3SUS
Tenth
-
Braided shield of tin-coated copper with minimum coverage of 85 percent.
Eleventh
-
Spirally-wrapped polyethylene terephthalate (polyester film) separator tape with a 25
percent minimum overlap.
Twelfth
-
Braided shield of tin-coated copper with minimum coverage of 85 percent.
Thirteenth
-
An optional binder.
Cross-linked polyolefin jacket (see table II for thickness).
Fourteenth
-
TABLE I. Details (unshieled).
Overall diameter
Cable jacket
Military part no.
Number of
Type and size
thickness min.
min.
max.
M24643/36
triads
avg. (inch)
(inch)
(inch)
-01UN
LS3SU-3
3
0.040
0.650
0.700
-02UN
LS3SU-7
7
0.050
0.840
0.910
-03UN
LS3SU-10
10
0.050
1.100
1.190
-04UN
LS3SU-14
14
0.050
1.200
1.290
-05UN
LS3SU-19
19
0.050
1.340
1.430
-06UN
LS3SU-24
24
0.060
1.580
1.670
-07UN
LS3SU-30
30
0.060
1.680
1.770
-08UN
LS3SU-37
37
0.060
1.840
1.930
-09UN
LS3SU-44
44
0.060
2.060
2.150
TABLE II. Details (shielded).
Overall diameter
Cable jacket
Military part no.
Number of
Type and size
thickness min.
min
max
M24643/36
triads
avg. (inch)
(inch)
(inch)
-01UD
LS3SUS-3
3
0.040
0.710
0.760
-02UD
LS3SUS-7
7
0.050
0.900
0.970
-03UD
LS3SUS-10
10
0.050
1.160
1.250
-04UD
LS3SUS-14
14
0.050
1.260
1.350
-05UD
LS3SUS-19
19
0.050
1.400
1.490
-06UD
LS3SUS-24
24
0.060
1.640
1.730
-07UD
LS3SUS-30
30
0.060
1.740
1.830
-08UD
LS3SUS-37
37
0.060
1.900
1.990
-09UD
LS3SUS-44
44
0.060
2.120
2.210
2
